2N IP Verso

• Progressive mobile access
• Touchscreen
• Camera with night vision

Brochure

Configuration Manual

Installation Manual

Signalling protocol

SIP 2.0 (RFC – 3261)

Buttons

Quick dial buttons
Transparent, white backlit buttons with easily replaceable name tags
Number of buttons
1 to 146
Numeric keypad optional

Audio

Microphone
1 integrated microphones
Loudspeaker 2W
Acoustic pressure for 1kHz at a distance of 1m 78 dB

Audio stream

Codecs
G.711, G.729, G.722, L16/16kHz

Camera

Resolution – JPEG 1280 x 960 px
Resolution – video call 640 x 480 px
View angle 120° (H), 90° (V), 145° (D)
IR Night Vision yes

Video stream

Codecs
H.263+, H.263, H.264, MJPEG, MPEG-4

RFID card reader

Supported cards 13.56MHz
Mifare Classic 1k & 4k, DESFire EV1, Mini, Plus S&X, SmartMX, Ultralight, Ultralight C, SLE44R35, my-d move (SLE66Rxx), PayPass, Legic Advant Calypso, Moneo, PicoPass, HID iCLASS
Supported cards 125kHz
EM4100, EM4102, HID Prox
NFC support: Yes, provided that HCE and 2N® Mobile Key application are included

Interface

Power supply 12V±15%/2A DC or PoE
PoE 802.3af (Class 0 – 12.95W)
LAN 10/100BASE-TX with Auto-MDIX, RJ-45
Relay outputs NC/NO contacts, max 30V/1A AC/DC
Active output 8V – 12V DC/400mA

Mechanical

Operating temperature range -40°C – 60°C
Storage temperature range -40°C – 70°C
Relative humidity 10% – 95% (not condensing)
Protection level IP 54

Dimensions

Wall-mounted 1 module
107x130x28 mm
Wall-mounted 2 modules
107x234x28 mm
Wall-mounted 3 modules
107x361x28 mm
In-wall 1 module
130x153x5 mm
In-wall 2 modules
130x257x5 mm
In-wall 3 modules
130x361x5 mm
